Chevrolet Cruze Repair Manual: Battery Disconnect Warning
Warning:Unless directed otherwise, the ignition and start switch must be in the OFF or LOCK position, and all electrical loads must be OFF before servicing any electrical component. Disconnect the negative battery cable to prevent an electrical spark should a tool or equipment come in contact with an exposed electrical terminal. Failure to follow these precautions may result in personal injury and/or damage to the vehicle or its components.
For Vehicles equipped with OnStar® (UE1) with Back Up Battery: The Back Up Battery is a redundant power supply to allow limited OnStar® functionality in the event of a main vehicle battery power disruption to the VCIM (OnStar®module). Do not disconnect the main vehicle battery or remove the OnStar® fuse with the ignition key in any position other than OFF. Retained accessory power (RAP) should be allowed to time out or be disabled (simply opening the driver door should disable RAP) before disconnecting power. Disconnecting power to the OnStar® module in any way while the ignition is On or with RAP activated may cause activation of the OnStar® Back-Up Battery (BUB) system and will discharge and permanently damage the back-up battery. Once the Back-Up Battery is activated it will stay on until it has completely discharged. The BUB is not rechargeable and once activated the BUB must be replaced.
Brake Dust Warning
Warning: Avoid taking the following actions when you service wheel brake parts:
- Do not grind brake linings.
- Do not sand brake linings.
- Do not clean wheel brake parts with a dry brush or with compressed air.
Some models or aftermarket brake parts may contain asbestos fibers which can become airborne in dust. Breathing dust with asbestos fibers may cause serious bodily harm. Use a water-dampened cloth in order to remove any dust on brake parts. Equipment is available commercially in order to perform this washing function. These wet methods prevent fibers from becoming airborne.
Brake Fluid Irritant Warning
Warning:Brake fluid may irritate eyes and skin. In case of contact, take the following actions:
- Eye contact--rinse thoroughly with water.
- Skin contact--wash with soap and water.
- If ingested--consult a physician immediately.
Checking Hot Transmission Fluid through Drain Plug Hole Warning
Warning:The engine must be running when the transmission fluid fill plug is removed, or excessive fluid loss will occur. Transmission fluid may be hot. Since the actual fluid level is unknown, stand clear when removing the fill plug. Have a container ready to capture any lost fluid. Do not turn the engine off with the fill plug removed, as you can be injured by hot transmission fluid being expelled out of the oil fill opening.
Cleaning Solvent Warning
Warning:Bodily injury may occur if the cleaning solvent is inhaled or exposed to the skin.
Collision Sectioning Warning
Warning: Sectioning should be performed only in the recommended areas. Failure to do so may compromise the structural integrity of the vehicle and cause personal injury if the vehicle is in a collision.
Cracked Window Warning
Warning:If a window is cracked but still intact, crisscross the window with masking tape in order to reduce the risk of damage or personal injury.
Defroster Outlet Warning
Warning:If broken glass falls into the defroster outlets, it can be blown into the passenger compartment and cause personal injury.
DOT 4 Brake Fluid Warning
Warning:When adding fluid to the brake fluid reservoir or to the clutch fluid reservoir, use only Super DOT-4 or equivalent DOT-4 brake fluid from a clean, sealed container. This polyglycol brake fluid is hygroscopic and absorbs moisture. Do not use fluid from an open container that may be contaminated with water. Improper or contaminated fluid could result in system failure, loss of vehicle control, and possible injury.
Exhaust Service Warning
Warning:In order to avoid being burned, do not service the exhaust system while it is still hot. Service the system when it is cool.
Express Window Down Warning
Warning:Disconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury.
Eye Protection Warning
Warning:Approved safety glasses and gloves should be worn when performing this procedure to reduce the chance of personal injury.
Foam Sound Deadeners Warning
Warning:Foam sound deadeners must be removed from areas within 152.4 mm (6 in) of where flame is to be used for body repairs.
When reinstalling foam sound deadeners, avoid inhaling fumes as bodily injury may result.
Steering Angle Sensor Calibration Warning
Warning: For vehicles with electric power steering (EPS) and without a vehicle stability enhancement program, the steering angle sensor MUST always be calibrated after the battery has been disconnected. Failure to calibrate the steering angle sensor could limit the operation of the EPS system ...
Warning: Refer to Approved Equipment for Collision Repair Warning in the Preface section. Warning: Refer to Collision Sectioning Warning in the Preface section. Warning: Refer to Glass and Sheet Metal Handling Warning in the Preface section. Disable the SIR System.
