Chevrolet Cruze Repair Manual: Center Pillar Upper Garnish Molding Replacement

Chevrolet Cruze Repair Manual: Center Pillar Upper Garnish Molding Replacement

Preliminary Procedure

Preliminary Procedure

  1. Remove the center pillar lower garnish molding. Refer to Center Pillar Lower Ga   rnish Molding Replacement
  2. Remove the seat belt from the front seat. Refer to Driver or Passenger Seat Retractor Side Belt Replacement
  1. Center Pillar Upper Garnish Molding Clip
  2. Center Pillar Lower Garnish Molding Assembly

Procedure

When replacing the center pillar lower garnish molding, remove the seat belt through the molding.

Center Pillar Lower Garnish Molding Replacement

Preliminary Procedure

Preliminary Procedure

  1. Remove the front side door sill trim plate. Refer to Front Side Door Sill  Trim Plate Replacement
  2. Remove the rear side door sill trim plate. Refer to Rear Side Door Sill Trim Plate Replacement.
  1. Center Pillar Lower Garnish Molding Clip (Qty: 6)
  2. Center Pillar Lower Garnish Molding Assembly

Quarter Window Garnish Molding Replacement

  1. Quarter Window Garnish Molding Assembly.
