Chevrolet Sonic Repair Manual: Intake Manifold Disassemble

Chevrolet Sonic Repair Manual: Intake Manifold Disassemble


  1. Remove the fuel injection rail ground cable nut (1).
  2. Remove the fuel injection rail ground cable nut (1).
  3. Remove the 2 fuel injection rail bolts (2).
  4. Remove the fuel injection fuel rail assembly (3).
  5. Remove the intake manifold gasket (4).
  6. Remove the 2 manifold absolute pressure sensor bolts (1).
  7. Remove the 2 manifold absolute pressure sensors (2).
  8. Remove the evaporative emission canister purge solenoid valve (3).
