Chevrolet Sonic Repair Manual: Selector and Shift Lever Cable Bracket Replacement

Chevrolet Sonic Repair Manual: Selector and Shift Lever Cable Bracket Replacement

Removal Procedure

  1. Remove the battery tray. Refer to Battery Tray Replacement.

  2. Disconnect the shift lever and selector lever cable end (1) from the transmission shift lever and selector lever.
  3. Pull the cable retainers (2) to release the shift lever and selector lever cable from the shift lever and selector lever cable bracket.
  4. Disconnect the shift lever and selector lever cable from the shift lever and selector lever cable bracket.
  5. Remove the 2 shift lever and selector lever cable bracket fasteners (1).
  6. Remove the shift lever and selector lever cable bracket (2) from the transmission.
Installation Procedure

  1. Position the shift lever and selector lever cable
  2. Position the shift lever and selector lever cable bracket (2) on the transmission.

    Caution:

    Refer to Fastener Caution.

  3. Install the 2 shift lever and selector lever cable bracket fasteners (1) and tighten to58 Y (43 lb ft)

    .



  4. Connect the shift lever and selector lever cable ends (1) to the transmission shift lever and selector lever.
  5. Pull the cable retainers (2), then position the shift lever and selector lever cable in the shift lever and selector lever cable bracket.
  6. Release the cable retainers (2) to connect the shift lever and selector lever cable to the shift lever and selector lever cable bracket.
  7. Adjust the shift lever and selector lever cables. Refer to Manual Transmission Shift Lever and Selector Lever Cable Adjustment.
  8. Install the battery tray. Refer to Battery Tray Replacement.
  9. Verify correct operation of the transmission control assembly.
