W/Harness Inspection
Check the vehicle speed sensor by using the scan tool.
(if normal, current vehicle speed is display)
Check if current vehicle speed is same as vehicle speed displayed on the GDS.

Check the damage to the connectors and wiring.
Check the power.
Turn ignition switch OFF.
Disconnect the vehicle speed sensor.
Turn ignition switch ON.
Check the voltage of the power terminal.
Specification : 11.5V 13.0V
Check the signal.
Turn ignition switch OFF.
Disconnect the vehicle speed sensor.
Turn ignition switch ON.
Check the voltage of the signal terminal.
Specification : 8.0V 11.5V
Check the ground.
Turn ignition switch OFF.
Disconnect the vehicle speed sensor.
Turn ignition switch ON.
Check the voltage between signal terminal and body ground.
Check the voltage between signal terminal and ground terminal.
Specification : (4) - (5) = Within 200mV
Component Inspection
IG KEY "OFF", ENGINE "OFF".
Disconnect the vehicle speed sensor connector.
Disconnect the vehicle speed sensor and driven gear.
Check the wear of spline (A).

Check rotating state of vehicle speed sensor driven gear.
Connect the vehicle speed sensor connector and IG KEY "ON".
Rotate the driven gear with hand.
Specification : Vehicle Speed Signal generates.
