Kia Forte: SS-A Solenoid Valve(ON/OFF) Removal - Automatic Transaxle Control System - Automatic Transaxle System - Kia Forte TD 2014-2018 Service ManualKia Forte: SS-A Solenoid Valve(ON/OFF) Removal

Disconnect the negative (-) battery cable.
Remove the air cleaner assembly and air duct.
(Refer to Engine Mechanical System - "Air cleaner")
Remove the under cover (A).
Tightening torque:
6.9 10.8 N.m (0.7 1.1 kgf.m, 5.1 8.0 lb-ft)

Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug.
(Refer to Hydraulic System - "Fluid")
Remove the air breather hose (A).
Remove the valve body cover (B).
Tightening torque:
11.8 13.7 N.m (1.2 1.4 kgf.m, 8.7 10.1 lb-ft)

Always replace the gasket of the eyebolt use new one whenever loosening eyebolt.


Remove installation bolts in the engin room first and then remove others under the vehicle.
Remove the bolt (3ea) after disconnecting the solenoid valve connector (B) and the oil temperature sensor connector (A).
Tightening torque:
9.8 11.8 N.m (1.0 1.2 kgf.m, 7.2 8.7 lb-ft)

Remove the solenoid valve (B) after removing the solenoid support (A).
