Special Service Tools

Item
Illustration
Application
Fuel Pressure Gauge
(09353-24100)

Measuring the fuel line pressure
Fuel Pressure Gauge Adapter
(09353-02100)

Connection between the high pressure fuel pump and the fuel feed line
Heated Oxygen Sensor Socket Wrench
(09392-2H100)

Removal and installation of the heated oxygen sensor
Torque Wrench Socket
(09314-3Q100)

Removal and installation of the high pressure fuel pipe
Injector Combustion Seal Guide & Sizing tool
(09353-2B000)

Installation of the injector combustion seal

Tightening Torques
Engine Control System Item kgf.m N.m lb-ft ECM installation bolt 1.0 1.2 9.8 11.8 7.2 8.7 ...
