System Outline
An optimal seat position set by a driver can be memorized in Power seat unit by IMS SW, which enables restoration of seat position set by the driver despite
Playing of this function during drive is banned for safety reasons, and it has emergency stop function of restoration and gearing operation as well
Input Specification
IGN switch input is determined by Local switch “IGN2”.
SEAT MANUAL switch : SEAT Input
SLIDE Front rear / rear right manual switch
Operating SLIDE motor of Seat either backward or forward
Recline Front rear / rear right switch
Operating recline motor of seat either backward or forward
Front rear height UP / DOWN manual switch
Operating Front rear height motor of SEAT either upward or downward
Rear right height UP / DOWN manual switch
Operating rear right height motor of SEAT either upward or downward
SEAT position Sensor (pulse Signal)
Sensing movement amount of Slide, Recline, Front rear height, and Rear right height motor
“P” Position switch
Sensing “P” position of SHIFT LEVER, not allowed for memory saving and easy access function by getting on and off a vehicle in the position other than “P.”
Dr Door switch
This signal is receiver for sensing state of dr door open state by BCM.
BCM KEY IN
This signal is received for sensing state of KEY by BCM
Local KEY IN switch
This signal is receiver for sensing state of KEY IN state by BCM.
Speed
This signal is received for sensing vehicle speed by BCM
IMS switch
SET switch
Allowing for saving the SEAT position set by driver
1, 2 switch
Saving and replaying the SEAT position set by driver
LIN Communication LINE
Transmitting communication signals between IMS switch and MEMORY P/SEAT (9600 bps)
CHATTERING Control in Input Signal
Input switch - 40ms delay
SLIDE, RECLINE, Front rear height, rear right HEIGHT switch
“P” Position switch, SPEED, KEY IN, LOCAL KEY IN switch, DR DOOR switch, IGN2 switch
IGN switch input is determined by Local switch “IGN2.
TIME Error
±10%, for TIME without error indication
±50ms, for TIME not exceeding 500ms
Indicated time in each function does not include Time of controlling CHATTERING started from changing point of rr input.
