Kia Sorento: Driver position memory system (if equipped, for power seat)

Kia Sorento: Driver position memory system (if equipped, for power seat) - Seats - Safety features of your vehicle - Kia Sorento XM Owners ManualKia Sorento: Driver position memory system (if equipped, for power seat)

A driver position memory system is provided to store and recall the driver seat


A driver position memory system is provided to store and recall the driver seat and outside rearview mirror position with a simple button operation.

By saving the desired position into the system memory, different drivers can reposition the driver seat based upon their driving preference.

If the battery is disconnected, the desired seat position memory will need to be re-saved.

WARNING

Never attempt to operate the driver position memory system while the vehicle is moving. This could result in loss of control, and an accident causing death, serious injury, or property damage.

Storing positions into memory using the buttons on the door

Storing driver’s seat positions

1. Shift the shift lever into P (for Automatic transaxle) while the engine start/stop button is ON or ignition switch ON.

2. Adjust the driver’s seat and outside rearview mirror comfortable for the driver.

3. Press SET button on the control panel. The system will beep once.

4. Press one of the memory buttons (1 or 2) within 5 seconds after pressing the SET button. The system will beep twice when memory has been successfully stored.

WARNING

Use caution when recalling the adjustment memory while sitting in the vehicle. Push the seat position control switch to the desired position immediately if the seat moves too far in any direction.

Recalling positions from memory

1. Shift the shift lever into P (for Automatic transaxle) while the engine start/stop button is ON or ignition switch ON.

2. To recall the position in the memory, press the desired memory button (1 or 2). The system will beep once, then the driver’s seat will automatically adjust to the stored position.

Adjusting the control switch for the driver’s seat while the system is recalling the stored position will cause the movement to stop and move in the direction that the control switch is moved.

Easy access function (if equipped)

The system will move the driver's seat automatically as follows:

  • Without smart key system It will move the driver’s seat rearward when the ignition key is removed. It will move the driver’s seat forward when the ignition key is inserted.
  • With smart key system It will move the driver’s seat rearward when the engine start/stop button is changed to the OFF position. It will move the driver’s seat forward when the engine start/stop button is changed to the ACC or START position.

Headrest (for front seat)

The driver's and front passenger's seats are equipped with a headrest for the


The driver's and front passenger's seats are equipped with a headrest for the occupant's safety and comfort.

The headrest not only provides comfort for the driver and front passenger, but also helps protect the head and neck in the event of a rear collision.

WARNING

  • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most people's head is similar with the height of the top of their eyes. Also, adjust the headrest as close to your head as possible. For this reason, the use of a cushion that holds the body away from the seatback is not recommended.
  • Do not operate the vehicle with the headrests removed. Severe injury to the occupants may occur in the event of an accident. Headrests may provide protection against neck injuries when properly adjusted.
  • Do not adjust the headrest position of the driver’s seat while the vehicle is in motion.

Adjusting the height up and down

To raise the headrest, pull it up to the desired position (1). To lower the headrest,


To raise the headrest, pull it up to the desired position (1). To lower the headrest, push and hold the release button (2) on the headrest support and lower the headrest to the desired position (3).

Adjusting the angle (if equipped)

The headrest angle may be adjusted by pulling or pushing the lower part of the


The headrest angle may be adjusted by pulling or pushing the lower part of the headrest.

Adjust the headrest so that it properly supports the head and neck.

CAUTION

Excessive pulling or pushing may damage the headrest.

Removal and installation

To remove the headrest:


To remove the headrest:

1. Recline the seatback (2) with the recline lever or switch (1).

2. Raise headrest as far as it can go.

3. Press the headrest release button (3) while pulling the headrest up (4).

WARNING

NEVER allow anyone to ride in a seat with the headrest removed.

To reinstall the headrest :


To reinstall the headrest :

1. Put the headrest poles (2) into the holes while pressing the release button (1).

2. Recline the seatback (4) with the recline lever or switch (3).

3. Adjust the headrest to the appropriate height.

WARNING

Always make sure the headrest locks into position after reinstalling and adjusting it properly.

Active headrest

The active headrest is designed to move forward and upward during a rear impact.


The active headrest is designed to move forward and upward during a rear impact. This helps prevent the driver's and front passenger’s heads from moving backward and thus helps minimize neck injuries.

For your safety, the active headrest can’t be removed. If there is any problem with the active headrest, take your vehicle to an authorized Kia dealer and have the system checked.

WARNING

A gap between the seat and the headrest release button may appear when sitting on the seat or when you push or pull the seat. Be careful not to get your finger, etc. caught in the gap.
