Main Power Window Switch Inspection
Disconnect the negative (-) battery terminal.
Remove the front door trim and power window switch.
(Refer to Body - "Front door")
Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Passenger Power Window Switch Inspection
Disconnect the negative (-) battery terminal.
Remove the front door trim and power window switch.
(Refer to Body - "Front door")
Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Rear Power Window Switch Inspection
Disconnect the negative (-) battery terminal.
Remove the rear door trim.
(Refer to Body - "Rear door")
Remove the rear power window switch module (A).

Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.
