Kia Sorento: Transaxle Control Module (TCM) Installation

Kia Sorento: Transaxle Control Module (TCM) Installation


When replacing the TCM, the vehicle equipped with the smart key system (Button start) must be performed procedure as below.
[In the case of installing used TCM]
1.
Perform "TCM Neutral mode" procedure with GDS.
(Refer to Body Electrical System - "Immobilizer System")
2.
After finishing "TCM Neutral mode", insert the key (or press the start button) and turn it to the IGN ON and OFF position. Then the TCM learns the smart key information automatically.
[In the case of installing new TCM]
Insert the key (or press the start button) and turn it to the IGN ON and OFF position. Then the TCM learns the smart key information automatically.
