Kia Soul: Parking Brake Cable. Installation

Kia Soul: Parking Brake Cable. Installation

Install the parking brake cable (A).
Tightening torque :
19.6 29.4 N.m (2.0 3.0 kgf.m, 14.5 21.7 lb-ft)

Install the parking brake cable (A), and then install the clip (B).

Install the parking brake cable (B).

Install the parking brake cable adjuster, then adjust the parking brake lever stroke by turning adjusting nut (A).
Parking brake lever stroke:
5 7 clicks (Pull the lever with 196N (20 kgf, 44 lbf))

Release the parking brake lever fully, and check that parking brakes do not drag when the rear wheels are turned. Readjust if necessary.
Make sure that the parking brakes are fully applied when the parking brake lever is pulled up fully.
Install the rear console cover (A).

Install the rear tire and wheel.
