As manual for diagnosis methods by using diagnosis device, the main contents are as follows:
Connect self-diagnosis connector(16pins) located in the lower of driver side crash pad to self-diagnosis device, and then turn the self-diagnosis device after key is ON.
Select the "vehicle model" and "TPMS" on GDS vehicle selection screen, then select OK.
[System Identification (Wireless)]

[Sensor ID Writing (Wireless)]

[VIN input initialization]

[Vehicle name input initialization]

[Sensor Status initialization]

[Register Sensor initialization]


Write ID Read ID and be sure to check are the same.
After registering successfully sensor "Sensor Wireless Information" by the execution determines whether the sensor is working properly.
