Mazda 3 Service Manual: Drive Belt Removal/Installation [Mzr 2.3 Disi Turbo]

1. Remove the aerodynamic under cover No.2 and splash shield as a single unit..

2. Rotate the drive belt auto tensioner in the direction shown in the figure and remove the drive belt.


3. Install the drive belt.

4. Verify that the drive belt auto tensioner indicator mark does not exceed the limit..

5. Install the aerodynamic under cover No.2 and splash shield as a single unit..
