Mazda 3 Service Manual: Variable Tumble Shutter Valve Switch Inspection [Mzr 2.0, Mzr 2.5]

Voltage Inspection

NOTE:

  • The variable tumble shutter valve switch cannot be removed as a single unit. When replacing the variable tumble shutter valve switch, replace it together with the intake manifold as a single unit.

1. Connect the M-MDS to the DLC–2.


2. Switch the ignition to ON.

3. Verify that the variable tumble shutter valve switch output voltage (PID: IMRC_POS) is within the specification..

  • If not as specified, replace the intake manifold..
