Start the engine, turn the fan control dial to the desired position, and press the button to activate the air conditioner. When the air conditioner is on, cooling and dehumidifying functions are added to the heater operation.

The air conditioner cooling function operates only when the engine is running.

Cooling

This mode is used to cool and dehumidify the air.

  1.  Press theair flow control button.
  2.  Turn the fan control dial to the desired position.
  3.  Push thebutton. The indicator light on thebutton will come on.
  4.  Turn the temperature control dial to the desired position.
  •  For quick cooling, push the MAX A/C button.

    When the MAX A/C button is pushed, it will activate themode. The amount of air coming through the vents is the highest it can go when in MAX A/C mode regardless of the position of the FAN dial.

Dehumidified heating

This mode is used to heat and dehumidify the air.

  1.  Press thebutton to the OFF position.
  2.  Press theair flow control button.
  3.  Turn the fan control dial to the desired position.
  4.  Push thebutton.
  5.  Turn the temperature control dial to the desired position.

Dehumidified defogging

This mode is used to defog the windows and dehumidify the air.

  1.  Press theair flow control button.
  2.  Turn the fan control dial to the desired position.
  •  When theor are selected, the air conditioner automatically turns on if the outside temperature is more than 36°F (2°C). This dehumidifies the air which helps defog the windshield. Themode automatically turns off, allowing outside air to be drawn into the passenger compartment to further improve the defogging performance.
  • The air conditioner is always on in ormode, regardless of whether the indicator light is on or off.
  1.  Turn the temperature control dial to the desired position.

Operating tips

  •  Keep the windows and moonroof closed while the air conditioner is in operation.
  •  After parking in the sun, drive for 2 or 3 minutes with the windows open to vent hot air from the passenger compartment. Then, close the windows. This allows the air conditioner to cool the interior more quickly.
  •  The air conditioning system should be operated for approximately 10 minutes at least once a month. This helps prevent damage to the system due to lack of lubrication.
  •  A visible mist may be seen coming from the ventilators in hot, humid conditions as the air is cooled rapidly. This does not indicate a malfunction.
  • If the engine coolant temperature gauge indicates engine coolant temperature over the normal range, turn the air conditioner off. For additional information, refer to “If your vehicle overheats” in the “In case of emergency” section of this manual.
  •  If the engine coolant temperature becomes too high,will be activated and the indicator light will come on automatically.
  •  When IGN is OFF, button characters will not illuminate.
Heater operation
Heating This mode is used to direct heated air to the foot outlets.
