Heating

This mode is used to direct heated air to the foot outlets. Some air also flows from the defrost outlets and the side vent outlets.

  1.  Press thebutton to change to fresh air intake mode. Theindicator light will turn off for normal heating.
  2.  Press theair flow control button.
  3.  Turn the fan control dial to the desired position
  4.  Turn the temperature control dial to the desired position between the middle and the hot position.

Ventilation

This mode directs outside air to the side and center vents.

  1.  Press thebutton to change to fresh air intake mode. Theindicator light will turn off.
  2.  Press theair flow control button.
  3.  Turn the fan control dial to the desired position.
  4.  Turn the temperature control dial to the desired position.

Defrosting or defogging

This mode directs the air to the defrost outlets to defrost/defog the windows.

  1. Press the defrost/defog button .
  2.  Turn the fan control dial to the desired position.
  3.  Turn the temperature control dial to the desired position between the middle and the hot position.
  •  To quickly remove ice or fog from the windows, turn the fan control dial to the highest setting and the temperature control to the full HOT position.
  •  When theposition is selected, the air conditioner automatically turns on if the outside temperature is more than 36°F (2°C).

    This dehumidifies the air which helps defog the windshield. Theindicator automatically turns off, allowing outside air to be drawn into the passenger compartment to further improve the defogging performance.

    The recirculation mode cannot be activated in theposition.

Bi-level heating

The bi-level mode directs warmed air to the side and center vents and to the front and rear floor outlets.

  1.  Press thebutton to change to fresh air intake mode. The will turn off.
  2.  Press theair flow control button.
  3.  Turn the fan control dial to the desired position.
  4.  Turn the temperature control dial to the desired position.

Heating and defogging

This mode heats the interior and defogs the windshield.

  1.  Press theair flow control button.
  2.  Turn the fan control dial to the desired position.
  3.  Turn the temperature control dial to the desired position between the middle and the hot position.
  •  When theposition is selected, the air conditioner automatically turns on if the outside temperature is more than 36°F (2°C).

    This dehumidifies the air which helps defog the windshield. Theindicator automatically turns off, allowing outside air to be drawn into the passenger compartment to further improve the defogging performance.

Operating tips

Clear snow and ice from the wiper blades and air inlet in front of the windshield. This improves heater operation.

Controls
Fan control dial The fan control dial turns the fan on and off, and controls fan speed. Air flow control buttons The air flow control buttons allow you to select the air flow outlets. MAX A/C � ...
Air conditioner operation
Start the engine, turn the fan control dial to the desired position, and press the button to activate the air conditioner.
