DTC Logic

NOTE: The Signal Tech II Tool [- (J-50190)] can be used to perform the following functions. Refer to the Signal Tech II User Guide for additional information.

  •  Activate and display TPMS sensor IDs
  •  Display tire pressure reported by the TPMS sensor
  •  Read TPMS DTCs
  •  Register TPMS sensor IDs

DTC DETECTION LOGIC

DTC

Display Item

Malfunction Detected Condition

Possible Cause

C1735 IGNITION SIGNAL LINE - BCM/ TPMS BCM has detected a mismatch between IGN ON signals BCM

DTC CONFIRMATION PROCEDURE

1.PERFORM SELF DIAGNOSTIC RESULT

With CONSULT

Perform Self Diagnostic Result.

Is DTC C1735 detected? YES >> Proceed to WT-36, "Diagnosis Procedure".

NO >> Inspection End.

Diagnosis Procedure

NOTE: The Signal Tech II Tool [- (J-50190)] can be used to perform the following functions. Refer to the Signal Tech II User Guide for additional information.

  •  Activate and display TPMS sensor IDs
  •  Display tire pressure reported by the TPMS sensor
  •  Read TPMS DTCs
  •  Register TPMS sensor IDs

1.CHECK CAN IGNITION SIGNAL

With CONSULT

  1.  Select “INTELLIGENT KEY” from “BCM” Data Monitor.
  2.  Check IGN RLY1-F/B value.

Monitor item

Displayed value

IGN RLY1 F/B

On with ignition in ON position

Is the inspection result normal? YES >> GO TO 2.

NO >> Check CAN system. Refer to LAN-17, "Trouble Diagnosis Flow Chart".

2.CHECK BCM POWER SUPPLY AND GROUND

Check BCM power supply and ground. Refer to BCS-68, "Diagnosis Procedure" (with Intelligent Key System) or BCS-128, "Diagnosis Procedure" (without Intelligent Key System).

Is the inspection result normal? YES >> GO TO 3.

NO >> Repair or replace harness or connectors.

3.DRIVE VEHICLE

Clear DTC and test drive vehicle to check for low tire pressure warning lamp.

Does the vehicle operate without any low tire pressure warning lamp? YES >> Inspection End.

NO >> Replace BCM. Refer to BCS-75, "Removal and Installation" (with Intelligent Key System) or BCS- 135, "Removal and Installation" (without Intelligent Key System).
