Exploded View

WITHOUT MOONROOF

Exploded View

  1. Map lamp assembly bracket
  2. Headlining
  3.  Assist grip (without coat hanger)
  4.  Map lamp assembly
  5. Sun visor holder (LH/RH)
  6. Sun visor (RH)
  7.  Sun visor cover
  8. Sun visor (LH)
  9.  Headlining cover
  10.  Assist grip (with coat hanger)
  11.  Top tether strap child restraint finisher

Front
Pawl

WITH MOONROOF

Exploded View

  1. Headlining
  2. Front assist grip bracket (LH)
  3. Map lamp assembly bracket
  4. Front assist grip bracket (RH)
  5.  Assist grip (with coat hanger)
  6.  Map lamp assembly
  7.  Assist grip (without coat hanger)
  8. Sun visor holder (LH/RH)
  9.  Sun visor (RH)
  10.  Sun visor cover (LH/RH)
  11.  Sun visor (LH)
  12.  Headlining cover
  13.  Top tether strap child restraint finisher

Front
Pawl

Removal and Installation

REMOVAL

WARNING: Before servicing the SRS, turn ignition switch OFF, disconnect both battery terminals then wait at least three minutes.

  1.  Disconnect negative and positive battery terminals, then wait at least three minutes. Refer to PG-77, "Removal and Installation".
  2.  Remove front pillar finisher (LH/RH). Refer to INT-20, "FRONT PILLAR FINISHER : Removal and Installation".
  3.  Remove center pillar upper finisher (LH/RH). Refer to INT-21, "CENTER PILLAR UPPER FINISHER : Removal and Installation".
  4.  Remove luggage side upper finisher (LH/RH). Refer to INT-36, "LUGGAGE SIDE UPPER FINISHER : Removal and Installation".
  5.  Remove map lamp assembly. Refer to INL-55, "Removal and Installation".
  6.  Disconnect map lamp assembly, personal lamp and microphone harness connectors.
  7.  Remove luggage side upper finisher (LH/RH). Refer to INT-36, "LUGGAGE SIDE UPPER FINISHER : Removal and Installation".
  8. Remove sun visor cover (LH/RH) (1) by inserting a suitable tool (A) as shown.

: Pawl

CAUTION: Do not damage headlining or sun visor cover surface.

Removal

  1. Remove sun visor screws (A) (LH/RH), then disconnect harness connectors and remove .

Removal

  1. Insert a suitable tool (A) at approximately a 30 degree angle into the sun visor holder notch on the front of the sun visor holder (1). Press in to release the locking tab (B). While holding in locking tab (B), turn the sun visor holder (1) 90 degrees to release it from the headliner.
  •  If the sun visor holder (1) does not fully rotate, make sure that the suitable tool (A) is pressing in on the locking tab (B) and is not positioned under locking tab (B). Reinsert the suitable tool (A) as necessary to release the locking tab (B).
  •  Front

CAUTION: Do not force the sun visor holder when removing as the locking tab may be damaged if the suitable tool is not positioned correctly.

Removal

  1. Remove front assist grip (LH/RH) and rear assist grip (LH/RH).
  1.  Remove assist grip cap (3).
  2.  Release clip (1) and remove assist grip (2).

Removal

  1. Insert suitable tool from front, release pawls then pull headlining cover (1) forward and outward to remove.

: Pawl
Front

Removal

  1. Insert two fingers through hole on headlining.

(A) :Tether

Removal

  1. Release tether (A) from hook (B) and remove.

Removal

  1. Remove screw (A) then release pawls using a suitable tool and remove child tether finisher (1).

    : Pawl

Removal

  1. Release headlining clip at rear and remove headlining through the back door.

CAUTION:

  •  When removing headlining, two workers are required.
  •  Do not bend headlining when removing.
  •  Be careful not to scratch or damage any part of the body while removing the headlining.

INSTALLATION

Installation is in the reverse order of removal.

CAUTION:

  •  Install sun-visor holder (LH/RH) and clips of the rear of headlining for positioning.
  •  Do not to bend the headlining when installing.
