Nissan Sentra Service Manual: CSC(concentric slave cylinder)

Nissan Sentra Service Manual: CSC(concentric slave cylinder)

Exploded View


  1. Transaxle assembly
  2. CSC (Concentric Slave Cylinder)

Removal and Installation

CAUTION:

  • Do not reuse CSC (Concentric Slave Cylinder). The CSC slides back to the original position every time the transaxle assembly is removed. This action may allow dust or contaminants to gather on the sliding parts and damage a seal of CSC causing clutch fluid leakage.
  • Do not disassemble CSC.
  • Keep painted surface on the body or other parts free of clutch fluid. If clutch fluid spills, wipe up immediately and wash the affected area with water.

REMOVAL

  1. Remove engine and transaxle assembly. Refer to TM-28, "Removal and Installation".
  2. Remove CSC bolts, then remove the CSC from transaxle assembly

INSTALLATION

  1. Install CSC to transaxle assembly, then tighten CSC bolts to the specified torque.

CAUTION:

  • Do not reuse CSC.
  • Do not install then operate CSC immediately, the piston and stopper of CSC components may fall off.
  1. Install engine and transaxle assembly in the reverse order of removal. Refer to TM-28, "Removal and Installation".

Inspection and Adjustment

INSPECTION AFTER INSTALLATION

Check for fluid leakage and the fluid level. Refer CL-7, "Inspection".

ADJUSTMENT AFTER INSTALLATION

Perform the air bleeding. Refer to CL-9, "Air Bleeding".
