Toyota Corolla Repair Manual: Handling of hose clamps

Toyota Corolla Repair Manual: Handling of hose clamps

  1. Before removing the hose, check the depth of the inserting portion and the clamp position in order to restore it surely.
  2.  change a deformed or dented clamp for a new one.
  3.  in case of reusing the hose, install the clamp on the hose where it has a clamp track.
  4.  for a spring type clamp, adjust it by adding force to the arrow mark direction after the installation.
