Components

Toyota RAV4. Rear speed sensor (for 4wd)


Removal

Hint:

  • Use the same procedures for the lh side and rh side.
  • The procedures listed below are for the lh side.
  1. Disconnect cable from negative battery terminal

Caution:

Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.

  1. Remove rear wheel
  2. Remove deck trim side panel assembly lh
  1. Remove the deck trim side panel lh (see page ir- 26).

Hint:

Refer to the procedures from the removal of the rear door scuff plate lh up until the removal of the deck trim side panel assembly lh.

  1. Remove rear speed sensor lh

Toyota RAV4. Remove rear speed sensor lh


  1. Disconnect the speed sensor connector.

Toyota RAV4. Remove rear speed sensor lh


  1. Disconnect the grommet of the speed sensor wire from the hole of the wheel house.

Toyota RAV4. Remove rear speed sensor lh


  1. Remove the bolt (labeled a) and sensor clamp (labeled b) from the side member.
  2. Remove the 2 nuts (labeled c) and sensor clamps (labeled d) from the upper arm.

Toyota RAV4. Remove rear speed sensor lh


  1. Remove the nut (labeled e) and sensor clamp (labeled f) from the trailing arm.
  2. Remove the bolt (labeled g) and sensor body (labeled h) from the carrier.

Notice:

Keep the sensor tip and sensor installation hole free from foreign matter.

Inspection

  1. Inspect rear speed sensor
  1. Check the speed sensor. If any of the following occurs, replace the speed sensor with a new one.
  • The surface of the speed sensor is cracked, dented, or chipped off.
  • The connector or wire harness is scratched, cracked, or damaged.
  • The speed sensor has been dropped.

Installation

Hint:

  • Use the same procedures for the lh side and rh side.
  • The procedures listed below are for the lh side.
  1. Install rear speed sensor lh

Notice:

To prevent interference with other parts, do not twist the sensor wire's painted line areas when installing it.

  1. Install the sensor (labeled a) with the bolt (labeled b).

Torque: 8.5 N*m (87 kgf*cm, 75 in.*Lbf)

Notice:

  • Keep the sensor tip and sensor installation hole free from foreign matter.
  • To prevent interference with the bearing rotor, do not rotate the sensor body when inserting the sensor body or after inserting the sensor body.
  1. Install the sensor clamp (labeled c) with the nut (labeled d).

Torque: 5.0 N*m (51 kgf*cm, 44 in.*Lbf)

Toyota RAV4. Install rear speed sensor lh


  1. Install the sensor clamps (labeled e) with the 2 nuts (labeled f).

Torque: 5.0 N*m (51 kgf*cm, 44 in.*Lbf)

Notice:

Do not twist the sensor wire when installing the clamps.

  1. Install the sensor clamp (labeled g) with the bolt (labeled h).

Torque: 8.5 N*m (87 kgf*cm, 75 in.*Lbf)

Notice:

Do not twist the sensor wire when installing the clamp.

Toyota RAV4. Install rear speed sensor lh


  1. Insert the connector and grommet to the inside of the vehicle through the passage hole in the wheel house.

Notice:

Make sure the grommet's band clamp remains on the outside of the vehicle.

Toyota RAV4. Install rear speed sensor lh


  1. Hold the grommet and pull it from the inside of the vehicle to the outside of the vehicle. Then fix it in place so that it is not tilted.

Notice:

  • When pulling out the grommet, do not grip the sensor wire.
  • Fix the grommet in place within the range shown in the illustration.

Toyota RAV4. Install rear speed sensor lh


  1. Connect the speed sensor connector.
  1. Install deck trim side panel assembly lh

Toyota RAV4. Install deck trim side panel assembly lh


  1. Install the deck trim side panel lh (see page ir-49).

Hint:

Refer to the procedures from the installation of the deck trim side panel lh up until the installation of the rear door scuff plate lh.

  1. Install rear wheel

Torque: 103 n*m (1,050 kgf*cm, 76 ft.*Lbf)

  1. Connect cable to negative battery terminal
  2. Check speed sensor signal
  1. Check the speed sensor signal (see page bc-28).
