Your preferred driving position (the position of the driver’s seat and outside rear view mirrors) can be recalled by pressing a button.

Two different driving positions can be recorded into memory.

Recording procedure

Toyota Sienna. Recording procedure


  1. Check that the shift lever is in P.
  2. Turn the engine switch to IGNITION ON mode.
  3. Adjust the driver’s seat and outside rear view mirrors to the desired positions.
  4. While pressing the “SET” button, or within 3 seconds after the “SET” button is pressed, press button “1” or “2” until the signal beeps.

    If the selected button has already been preset, the previously recorded position will be overwritten.

Recall procedure

Toyota Sienna. Recall procedure


  1. Check that the shift lever is in P.
  2. Turn the engine switch to IGNITION ON mode.
  3. Press one of the buttons for the driving position you want to recall until the signal beeps.

To stop the position recall operation part-way through

Perform any of the following:

  • Press the “SET” button.
  • Press button “1” or “2”.
  • Operate any of the seat adjustment switches (only cancels seat position recall).

Operating the driving position memory after turning the engine switch off

Recorded seat positions can be activated up to 180 seconds after the driver’s door is opened and another 60 seconds after it is closed again.

In order to correctly use the driving position memory function

If a seat position is already in the furthest possible position and the seat is operated in the same direction, the recorded position may be slightly different when it is recalled.

Power easy access system
The seat is automatically adjusted to allow the driver to enter and exit the vehicle easily. When all of the following have been performed, the driver’s seat is automatically adjusted to a po ...
Memory recall function
Each electronic key can be registered to recall your preferred driving position. Registering procedure Record your driving position to button “1” or “2” before performing the following: C ...
