INSPECTION PROCEDURE

1 CHECK CABIN

  1. Check the cabin for any object that might interrupt radio reception on the instrument panel. If such an object exists, remove it and check if the GPS mark reappears.

HINT: The GPS uses extremely faint radio waves originating from satellites. If the signal is interrupted by obstructions or other radio waves, the GPS may not be able to properly receive the signal.

OK: Mark appears

NORMAL OPERATION

2 CHECK SURROUNDINGS

  1. Check if the vehicle is in a location where GPS signal reception is poor. If the vehicle is in such a place, relocate the vehicle and check if the GPS mark reappears.

HINT: The GPS uses 24 satellites in 6 orbits. At any point in time, 4 satellites should be able to pinpoint your vehicle.

However, GPS signals may not reach the vehicle due to influence from the surroundings, vehicle direction, and time. For illustrated examples, see below.

CHECK SURROUNDINGS

OK: GPS mark is displayed.

SYSTEM RETURNS TO NORMAL

3 CHECK GPS INFORMATION (NAVIGATION CHECK MODE)

 CHECK GPS INFORMATION (NAVIGATION CHECK MODE)

  1. Enter the "Navigation Check" mode (GPS Information).
  2. Check how many of the following codes appear in the "STS" column.
