Toyota Sienna Service Manual: Meter Illumination does not Dim at Night

Toyota Sienna Service Manual: Meter Illumination does not Dim at Night

DESCRIPTION

  •  Confirm that the vehicle is equipped with the optitron meter, then check this circuit.
  •  The combination meter assembly receives a auto dimmer signal from the body ECU by the multiplex communication line.

WIRING DIAGRAM

WIRING DIAGRAM

INSPECTION PROCEDURE

1 CHECK MULTIPLEX COMMUNICATION SYSTEM

  1. Check if MULTIPLEX communication DTC is output

Result

Result

2 CHECK DTC

  1. Check if the DTC B1244 is output

Result

Result

3 PERFORM ACTIVE TEST BY INTELLIGENT TESTER

  1. Operate the intelligent tester according to the steps on the display and select "DATA LIST".

MAIN BODY

MAIN BODY

OK: The meter illumination is dimmed when the DIMMER SIG is ON.

CHECK LIGHTING SETTING

4 REPLACE COMBINATION METER ASSEMBLY

OK: The operation of the combination meter assembly returns to normal.

END
