DESCRIPTION

Factors that affect the indicated vehicle speed include tire size, tire inflation, and tire wear. The speed indicated on the speedometer has an allowable margin of error. This can be tested using a speedometer tester (calibrated chassis dynamometer). For details about testing and the margin of error, see the reference chart.

WIRING DIAGRAM

WIRING DIAGRAM

INSPECTION PROCEDURE

NOTICE: If the vehicle speed is outside the allowable range when tested, perform the following procedure.

1 PERFORM ACTIVE TEST BY INTELLIGENT TESTER

  1. Connect the tester to the DLC3.
  2.  Turn the ignition switch to the ON position.
  3.  Turn the tester ON.
  4.  Enter the following menus: DIAGNOSIS / OBD/MOBD / METER / ACTIVE TEST
  5.  Check the operation by referring to the values in the table below.

METER:

METER

*1: for U.S.A.
*2: Except for U.S.A.

OK: Needle indication is within the allowable range.

2 READ VALUE OF INTELLIGENT TESTER

  1. Connect the intelligent tester to the DLC3.
  2.  Turn the ignition switch to the ON position.
  3.  Turn the tester ON.
  4.  Enter the following menus: DIAGNOSIS / OBD/MOBD / METER / DATA LIST.
  5.  Check the values by referring to the values in the table below.

METER:

METER

OK: Vehicle speed displayed on the tester is almost the same as the actual vehicle speed measured using a speedometer tester (calibrated chassis dynamometer).

REPLACE COMBINATION METER ASSEMBLY

3 READ VALUE OF INTELLIGENT TESTER

  1. Connect the intelligent tester to the DLC3.
  2.  Turn the ignition switch to the ON position.
  3.  Turn the tester ON.
  4. Enter the following menus: DIAGNOSIS / ABS/TRAC/ VSC / DATA LIST.
  5.  Check the values by referring to the values in the table below.

ABS/TRAC/VSC:

ABS/TRAC/VSC

OK: Vehicle speed displayed on the tester is almost the same as the actual vehicle speed measured using a speedometer tester (calibrated chassis dynamometer).

4 INSPECT COMBINATION METER ASSEMBLY

INSPECT COMBINATION METER ASSEMBLY

  1. Disconnect the S3 connector.
  2.  Measure the voltage according to the value(s) in the table below.

Standard voltage

Standard voltage

*1: without VSC
*2: with VSC

Result

Result

5 INSPECT COMBINATION METER ASSEMBLY

INSPECT COMBINATION METER ASSEMBLY

  1. Check the input signal waveform.
  1.  Remove the combination meter assembly with connector(s) still connected.
  2.  Connect the oscilloscope to terminal C10-35 (SI) and body ground.
  3.  Turn the wheel slowly.
  4.  Check the signal waveform according to the condition(s) in the table below.

INSPECT COMBINATION METER ASSEMBLY

OK: The waveform is displayed as shown in the illustration.

HINT: As the vehicle speed increases, the cycle of the signal waveform narrows.

Result

Result

REPLACE COMBINATION METER ASSEMBLY

6 CHECK HARNESS AND CONNECTOR (COMBINATION METER - BRAKE ACTUATOR ASSEMBLY)

CHECK HARNESS AND CONNECTOR (COMBINATION METER - BRAKE ACTUATOR ASSEMBLY)

  1. Disconnect the S3 and C10 connectors.
  2.  Measure the resistance according to the value(s) in the table below.

Standard resistance

Standard resistance

REPLACE COMBINATION METER ASSEMBLY

7 CHECK HARNESS AND CONNECTOR (COMBINATION METER - ABS & TRACTION ACTUATOR ASSEMBLY)

CHECK HARNESS AND CONNECTOR (COMBINATION METER - ABS & TRACTION ACTUATOR ASSEMBLY)

  1. Disconnect the S3 and C10 connectors.
  2. Measure the resistance according to the value(s) in the table below.

Standard resistance

Standard resistance

REPLACE COMBINATION METER ASSEMBLY

Tachometer Malfunction
DESCRIPTION The meter CPU receives the engine revolution signal from the ECM via the direct lines. The meter CPU displays engine revolution data that is calculated based on the data received fro ...
